Mac Studio M3 Ultra vs Dual RTX 5090 for Local AI in 2026: 512GB vs 64GB, and a Used Mac That Costs More Than Both

By RunAIHome Team · 12 min read
mac-studioapple-siliconrtx-5090multi-gpulocal-llmhardwarecomparisonhigh-vram

TL;DR: This matchup used to be $9,499 vs ~$9,050 — the classic capacity-vs-speed decision. Then Apple killed the 512GB Mac Studio in March 2026, and used units now ask $18,250–$27,500 while two RTX 5090s still cost about $9,050. The Mac runs 671B-class MoE models at 17–20 tok/s under 200W; the 5090 pair is 2–3× faster on everything that fits in 64GB and draws 1,150W doing it.

Product update (Sep 28 2026): Apple replaced the M3 Ultra Mac Studio with the M5 Ultra in August 2026 — $5,499 to start, 1.2 TB/s (up from 819 GB/s), and 96/256/512GB of unified memory ($9,499 at 256GB). The M3 Ultra is now a used-market part. The architecture comparison below is unchanged; the price and bandwidth numbers for the Apple side are the old generation’s. See the M5 Ultra if you are buying new.

Used M3 Ultra 512GB2× RTX 5090 (64GB)M5 Ultra 256GB (new)
Best for400GB-class MoE quants, silent and low-powerMax speed on ≤64GB models, image/video genSame idea as the M3 Ultra, with warranty
Price (Sep 2026)$18,250–$27,500 used/refurb~$8,400–$10,400 in cards~$9,499, ships from Sep 22
Memory512GB unified, 819 GB/s64GB split 32+32, 1,792 GB/s per card256GB unified, 1.2 TB/s
Power under load<200W~1,150W (whole rig)~200W class
The catchCosts 2× its 2025 price, zero warranty64GB ceiling, big MoE models don’t fit512GB tier not orderable until late October

Honest take: Do not pay $18,000+ for a discontinued Mac. If you need the 512GB tier, pre-order the M5 Ultra or wait for its October 512GB config; if your models fit in 64GB, the dual-5090 rig — or honestly a single 5090 — wins on raw speed. The used M3 Ultra at current asks loses to both.

When we compared the M3 Ultra against dual RTX 4090s back in May, the premise was simple: both setups cost roughly the same, so pick capacity or speed. That premise is dead, and the way it died says a lot about what 2026’s DRAM shortage is doing to the high-VRAM market. Before you read on, check what your target models actually need against the VRAM calculator — this entire comparison hinges on whether your workload fits in 64GB.

What happened to the price

Apple launched the Mac Studio M3 Ultra in March 2025 with up to 512GB of unified memory — the 32-core CPU / 80-core GPU chip with 512GB and a 1TB SSD came to $9,499. For eighteen months it was the only machine under $10K that could hold a 400GB model in one memory pool, and r/LocalLLaMA treated it accordingly.

Then, between March 4 and 6, 2026, the 512GB option quietly disappeared from Apple’s configurator. The $4,000 upgrade tier was pulled outright and the 256GB tier got $400 more expensive — the same global DRAM squeeze that froze NVIDIA’s consumer GPU roadmap hit Apple’s build-to-order list. The 256GB option followed in May, leaving the M3 Ultra at 96GB only, and the August 25 refresh replaced the chip entirely with the M5 Ultra.

The result is a genuine collector’s market for a two-generation-old computer. On eBay as of mid-September 2026, sealed refurbished 512GB/1TB units ask $18,250, an Apple-certified seller lists the 512GB/1TB config at $23,499, and 512GB/4TB units run $25,700–$27,500. A machine that cost $9,499 new now trades at roughly double — because for six months, no new machine could replace it, and the M5 Ultra’s 512GB config still can’t be ordered until late October.

Two RTX 5090s, meanwhile, cost what they cost in the summer: Pangoly’s tracker averaged $4,525 per card on September 13, with Micro Center stock near $4,200 and the best widely-available price at $5,199. Call the pair $8,400 if you’re patient, $10,400 if you’re not — the same ~$9,050 realistic midpoint we used in yesterday’s RTX PRO 6000 comparison.

So the “which should you buy” question now has a third answer hiding inside it, and we’ll be honest about that throughout: the M5 Ultra 256GB at ~$9,499 makes the used M3 Ultra hard to justify for almost everyone.

The physics: 819 GB/s vs 1,792 GB/s

Single-stream token generation is memory-bandwidth-bound — the GPU spends its time reading weights, not doing math. The M3 Ultra moves 819 GB/s across its whole 512GB pool. Each RTX 5090 moves 1,792 GB/s across its 32GB. That 2.2× bandwidth gap is why, on any model both machines can hold, the NVIDIA side generates tokens roughly twice as fast — and it’s also why the second 5090 doesn’t speed up decode at all. Splitting a model across two cards doubles capacity and parallelizes prompt processing; the token stream still walks the weights sequentially. We measured exactly this on dual R9700s, where a second card moved dense-model decode from 24.85 to 24.31 tok/s.

Here’s how the verified numbers stack up:

WorkloadM3 Ultra 512GB2× RTX 5090 (64GB)
gpt-oss-20b (fits anywhere)115.5 tok/s282.5 tok/s (one card, second idle)
Llama 3.3 70B Q4_K_M (~42.5GB)~25–30 tok/s (MLX)~27 tok/s split across both
gpt-oss-120b (~63GB + context)79.7 tok/s, 1,244 tok/s prefillFits only with CPU-spilled experts at 32K ctx
DeepSeek V3/R1 671B Q4 (~404GB)17–20 tok/sDoes not fit, at any quant worth running

The gpt-oss numbers come from the official llama.cpp benchmark thread (M3 Ultra 80-core and RTX 5090 on the same build); the 70B figures are Ollama 0.6.5 and MLX respectively, so treat the exact values gently — but the pattern is consistent. Small models: NVIDIA by 2.4×. Dense 70B: a tie, because 42.5GB of weights split across two PCIe cards spends its bandwidth advantage on coordination. Above 64GB: the Mac is the only one still standing.

What only 512GB can do — and the catch nobody mentions

The M3 Ultra 512GB’s party trick remains genuinely unmatched by any consumer GPU rig: it holds a 671B-parameter MoE model in one memory pool. MacRumors verified DeepSeek R1 671B at 4-bit running 17–18 tok/s, with the model’s 404GB footprint requiring about 448GB of wired GPU memory, and TechRadar confirmed the whole machine draws under 200W doing it. DeepSeek V3’s 4-bit MLX build clocks about 20 tok/s. To match that capacity with 5090s you’d need fourteen cards.

Getting there involves one real config step. macOS caps how much unified memory the GPU may wire by default, and a 404GB model blows past it. The fix is raising the limit before loading:

$ sudo sysctl iogpu.wired_limit_mb=458752
iogpu.wired_limit_mb: 0 -> 458752

That allocates 448GB to the GPU (leaving ~64GB for the OS). Skip it and the model load fails or silently spills, and you’ll be staring at single-digit tok/s wondering why your $18K machine is slow. The setting resets on reboot.

Now the catch: prompt processing. Apple Silicon’s weakness has never been decode — it’s prefill compute. Hardware Corner fed the 671B model a long prompt under llama.cpp and waited 14 minutes for the first token. MLX is dramatically better (its prefill runs 4–5× faster on big MoE models), but even the healthy 1,244 tok/s prefill on gpt-oss-120b is a quarter of what a single RTX PRO 6000 does on the same model. If your workflow is agentic coding — stuffing 50K tokens of repo context into every request, the way Cline and Cursor BYOK setups do — the Mac spends its life prefilling. If it’s long chat sessions with incremental context, the KV cache carries over and the weakness barely shows. Our 100B-models-on-Mac guide covers which serving stacks handle this best.

What the dual-5090 rig does better

Everything under 64GB, roughly twice as fast — and everything parallel, four times as fast. Two full GB202 dies are a small render farm: batched ComfyUI image generation, two models served simultaneously (a coder on card 0, a chat model on card 1), video generation workloads that saturate a single 5090. A single 5090 posts 282 tok/s on gpt-oss-20b where the Mac posts 115. Prompt processing on the NVIDIA side is measured in five digits.

The 64GB ceiling is real, though, and it sits at an awkward height in September 2026. The most interesting open models cluster just above it: gpt-oss-120b wants 64.9GB at 32K context — a sub-gigabyte miss that forces MoE expert layers into system RAM via --n-cpu-moe, which works but costs throughput and the other 99K tokens of context. GLM and Qwen’s flagship MoE quants are further out of reach. The dual-5090 rig is the fastest possible home for the previous generation of model sizes, at the exact moment model sizes moved up a tier.

And it pays for its speed at the wall: ~1,150W under load for the whole rig against the Mac’s sub-200W. At $0.12/kWh that’s $0.138/hour versus $0.024/hour — run inference 8 hours a day and the gap is about $333 a year, before you price the 1,600W PSU, the case that fits two 3.5-slot cards, and the room getting warm. Our PSU sizing guide covers the build side.

What to actually buy

Prices as of September 2026, all taken from the comparison above:

Your situationThe machinePriceWhere
Everything you run fits in 32GBSingle RTX 5090~$4,200–$5,199Check price
Two parallel workloads, each ≤32GB2× RTX 5090~$8,400–$10,400Check price
You want 200GB+ models, quiet, warrantiedMac Studio M5 Ultra 256GB~$9,499Check price
You must run 671B-class today, money no objectUsed M3 Ultra 512GB$18,250–$27,500eBay / refurb market only
Undecided — want to test the workload firstRented GPU, ~$1–2/hrpay per hourRunPod

The used M3 Ultra row is there for completeness, not as a recommendation. At $18,250 minimum you’re paying a $8,700+ premium over the machine’s launch price for hardware with no warranty, 819 GB/s bandwidth that the M5 Ultra beats by 46%, and a seller market propped up entirely by a supply gap that closes in late October when the M5 Ultra’s 512GB config opens for orders. The one scenario where it makes sense: you need 400GB of unified memory this month and the workload pays for itself. Everyone else should rent the big-model experience by the hour on RunPod — an H200 at ~$3/hr will tell you whether you actually use 671B-class models enough to buy hardware for them — or self-host the mid-size tier with Ollama or vLLM on cards you already own.

FAQ

Isn’t the used M3 Ultra price just seller fantasy? Partly — those are asking prices, and asks above $25K likely sit unsold. But the floor is real: sealed refurb 512GB units at $18,250 reflect six months in which no orderable machine offered more than 256GB of unified memory. Expect asks to fall once M5 Ultra 512GB orders open in late October; that’s another reason not to buy now.

Can I pool two 5090s into one 64GB model the way the Mac pools 512GB? Functionally yes for capacity — llama.cpp --tensor-split and vLLM tensor parallelism load half the model per card. But decode speed doesn’t scale with the second card, PCIe coordination adds overhead, and there’s no NVLink on the 5090. It’s two 32GB cards cooperating, not one 64GB card.

Does the M3 Ultra’s Neural Engine help LLM inference? No — MLX and llama.cpp run on the GPU cores. The ANE reverse-engineering work making the rounds this week is research-grade profiling, not a faster inference path; bandwidth, not the NPU, is what decides tok/s on this machine.

What about a used M3 Ultra 96GB instead? At the right price it’s a reasonable quiet-box alternative to a Strix Halo mini PC, but 96GB buys no new model class over the $1,999–$3,500 x86 options, and Apple’s own refurb store sells it with a warranty. The 512GB config is the only tier where the M3 Ultra was ever unique.

  • RTX 5090 — 32GB GDDR7, 1,792 GB/s; the fastest consumer card for anything that fits
  • Mac Studio M5 Ultra — the machine to buy if the 512GB M3 Ultra tempted you

Sources

Last updated September 15, 2026. Prices and specs change; verify current rates before purchasing.
